Project Gallery
Explore our real-world engineering portfolio showcasing cable assemblies, custom box builds, MIL-SPEC interconnects, 3D printing setup, and precision component close-ups.
3D Printing & Additive Manufacturing Setup
In-house FDM additive manufacturing facility with multi-material 3D printers for rapid prototyping, mounting brackets, and custom assembly fixtures.
Precision Assembly & Integration Workbench
Dedicated electromechanical assembly facility equipped with precision crimping tools, optical inspection, and custom wire harness fixtures.
Rapid Prototyping & Testing Lab
Dual high-precision 3D printing and test bench setup for rapid iteration and component prototyping.
Precision Soldering as per IPC Class-3
Disciplined hand-soldering workmanship meeting high-reliability IPC/WHMA-A-620 Class 3 standards.
Ruggedized Electro-Mechanical Box Build
Full chassis integration with potted connectors, internal wire routing, strain relief, and sub-assembly testing.
Specialized UAV Control Wire Harness
Lightweight, high-flexibility control cabling engineered for unmanned aerial vehicle platforms.
Micro-D Soldered Interconnect
Precision micro-soldering and dual-wall heat-shrink insulation under optical magnification.
Low-Volume Prototype Cable Build
Rapid turnaround prototype harness build for early-stage engineering validation and field testing.
MIL-SPEC Aerospace Harness Assembly
Shielded MIL-SPEC cable assembly with braided EMI protection and strain-relief backshells.
Rackmount Electronics Enclosure Routing
Custom modular rack enclosure integration featuring structured wire management and QC inspection validation tags.
Micro Solder Joint Y-Splice Inspection
High-magnification inspection of an in-line wire Y-splice solder junction prior to insulation sealing.
Micro D-Sub Gold Receptacle Assembly
Compact 9-pin micro D-sub panel mount receptacle with gold-plated contact pins and strain-relieved leads.
Shielded Coaxial RF Cable Assembly
Precision coaxial cable with BNC & TNC terminations, heat-shrink strain relief, and serialized wire tags.
MIL-DTL Circular Connector Backshell
Ruggedized circular connector assembly with woven metallic EMI shielding braid and crimped contact leads.
High-Density Gold Pin Contact Crimps
Close-up face view of crimped gold-plated pin contacts and woven EMI braid internal to a circular connector shell.
MIL-SPEC Flange Receptacle Face
Square flange panel-mount MIL-SPEC receptacle with gold pin contacts and letter-keyed pinout array.
ITT Cannon ZIF 156-Pin High-Density Connector
ITT Cannon DL1-156P Zero Insertion Force (ZIF) high-density multi-contact connector header.
Multi-Branch ZIF-to-D-Sub Breakout Harness
Complex wire harness splitting a 156-pin ZIF header into multiple D-sub connector channels.
Precision Micro-Crimp Terminal Pin Terminations
Precision hand-crimped terminal pin terminations on insulated wire leads for high-reliability harness builds.
High-Density Hand-Crimped Lead Bundle
Structured bundle of individual hand-crimped wire leads ready for connector insertion.
Automotive System Wire Harness
Precision wiring harness built for EV powertrain and sensor integration.
